XDAQ CORE LED Indicators

SYS

[ON]

Program Loaded


[Flashing]

Hardware Error

S1

[ON]

Acquisition ON

S2

[Flashing]

Activities* in DIN1

S3

[Flashing]

Activities* in DOUT1




P1

[ON]

Headstage Detected on Port 1 (after software initialization)

P2

[ON]

Headstage Detected on Port 2 (after software initialization)

P3

[ON]

Headstage Detected on Port 3 (after software initialization)

P4

[ON]

Headstage Detected on Port 4 (after software initialization)


XDAQ ONE LED Indicators

SYS

[ON]

Program Loaded


[Flashing]

Hardware Error

S1

[ON]

Acquisition ON

S2

[Flashing]

Activities* in DIN1 and DIN2

S3

[Flashing]

Activities* in DOUT1 and DOUT2




STIM

[ON]

XDAQ™ in StimRecord (SR) Mode

V1

[ON]

VStim level set to +/- 7V

V2

[ON]

VStim level set to +10/-4V

V3

[ON]

VStim level set to +4/-10V




Port 1

[ON]

Headstage Detected on Port 1 (after software initialization)

Port 2

[ON]

Headstage Detected on Port 2 (after software initialization)

Port 3

[ON]

Headstage Detected on Port 3 (after software initialization)

Port 4

[ON]

Headstage Detected on Port 4 (after software initialization)


* DIN, DOUT flash rate is deliberately slowed down for visualization purposes
